Using SQL for data analysis

If you’re asked to do any data analysis, you immediately power up a Jupyter notebook and start flexing your .ipynb muscles, right? Data analysis means Python and it means R. The only SQL you need is for reading the data out of the database. Then you turn to a proper analysis language.

But SQL is insanely powerful. It’s much, much more than SELECT *. In fact, that’s the worst part of it! The power of SQL means you can do a ton of data analysis basically within your database. SQL is designed to manage, manipulate, and query data efficiently. It's particularly adept at handling large datasets quickly and can perform complex aggregations, joins, and calculations on the fly.

It is designed to do these tasks on the database server itself, reducing the amount of data that needs to be pulled over the network and into memory, as you’d see with Python and R.

So let’s go through how you might use SQL for data analysis. We’ll get through:

• The basic manipulations and queries that you use as the building blocks of analysis in SQL

• The more sophisticated techniques you can use to aggregate and calculate data

• How to build stored procedures to quickly implement data analyses within databases

• How to optimize and tune your queries and performance to reduce overhead and costs.

Let’s get to it.

The foundations of data analysis with SQL

Let’s say we’re a data analyst working for a SaaS company doing some data modeling. We want to use SQL with our datasets to perform some data aggregation and data mining.

SQL is a great option for this task because:

1. One of the advantages of SQL is its simplicity and the ease with which you can chain together its functions to create more complex queries. SQL has a relatively small set of core commands: SELECT, FROM, WHERE, GROUP BY, HAVING, ORDER BY, and JOIN, among others. These commands can be combined and nested in various ways to extract, filter, sort, and analyze data.

2. But SQL also includes a wide range of additional functions and capabilities, including mathematical and statistical functions, string manipulation functions, date and time functions, and advanced features like subqueries, window functions, and stored procedures.

So, the simplicity and consistency of SQL's core commands make it easy to get started and to understand what a query is doing. At the same time, its powerful set of functions and features enables complex and sophisticated data analysis and data modeling.

Before we can get started, we’ll need some data. Because of the way databases and SQL work, we’ll create two tables for these examples, subscriptions and users:

The subscriptions table looks like this:

And the users table looks like this:

You can generate data like this with Mockaroo, a great option for generating large amounts of test data for database or API testing.

Let’s go through those simple commands first.

SELECT

Pretty much the most basic SQL command. This command is used to select data from a database. You can select one or multiple columns.

SELECT user_id, sign_up_date
    FROM users;

Output:

WHERE

The WHERE clause is used to filter records based on specific conditions. Here we want to just get a single user from our users table, the user with user_id = 1:

SELECT *
    FROM users
    WHERE user_id = 1;

Output:

GROUP BY

The above two commands just let you select the raw data from the tables. However, the GROUP BY statement groups rows that have the same values in specified columns into aggregated data. Here we’re counting the number of subscriptions we have for each of our two plans:

SELECT plan_id, COUNT(*) as count
    FROM subscriptions
    GROUP BY plan_id;

Output:

HAVING

The HAVING clause was added to SQL because the WHERE keyword could not be used with aggregate functions. So we can aggregate with GROUP BY then select with HAVING (in this case finding the plan with more than 2 members):

SELECT plan_id, COUNT(*) as count
    FROM subscriptions
    GROUP BY plan_id
    HAVING COUNT(*) > 2;

Output:

ORDER BY

The ORDER BY keyword is used to sort the result-set in ascending or descending order. Let’s see who signed up most recently:

SELECT *
    FROM users
    ORDER BY sign_up_date DESC;

Output:

JOIN

A JOIN clause is used to combine rows from two or more tables, based on a related column between them. JOINs are one of the most common needs in SQL and where the benefits of SQL come into play as you don’t have to pull all the data from different tables as you would with Python and R. Here we’ll JOIN our two tables on the user_id field:

SELECT *
    FROM users
    JOIN subscriptions ON users.user_id = subscriptions.user_id;

Output:

Subquery

A Subquery or Inner query or Nested query is a query within another SQL query and embedded within the WHERE clause. Subqueries are used to return data that will be used in the main query as a condition to further restrict the data to be retrieved. This one it's shows the subscriptions that have a price higher than the average subscription price.

SELECT *
    FROM subscriptions
    WHERE price > (SELECT AVG(price) FROM subscriptions);

Output:

CASE

The CASE statement goes through conditions and returns a value when the first condition is met. It works kinda like an if/else statement in other languages. Once a condition is true, it will stop reading and return the result. If no conditions are true, it returns the value in the ELSE clause. We can use it to categorize our subscriptions:

SELECT user_id,
           price,
           CASE
               WHEN price >= 150 THEN 'High'
               WHEN price >= 100 THEN 'Medium'
               ELSE 'Low'
           END as price_category
    FROM subscriptions;

Output:

And with that, you genuinely have almost everything you need to start generating extremely powerful queries for data analysis with SQL.

More complex SQL for data analysis

With the above tools, you can do a huge amount, especially when it comes to just data wrangling and data mining. But most of them aren’t doing real calculations.

You can use those functions get SQL to do the heavy lifting for data manipulation before going into more detailed analysis in Python or R. But SQL can also do more complex analysis. Let’s go through some of the more sophisticated techniques data analysts can use with SQL

Window functions

Window functions perform a calculation across a set of table rows that are somehow related to the current row.

This is comparable to the type of calculation that can be done with an aggregate function. But unlike regular aggregate functions, the use of a window function does not cause rows to become grouped into a single output row — the rows retain their separate identities.

SELECT user_id,
           start_date,
           price,
           SUM(price) OVER (PARTITION BY user_id ORDER BY start_date) as running_total
    FROM subscriptions;

Output:

PARTITION_BY

The PARTITION BY clause is used in conjunction with window functions in SQL. This clause divides the result set produced by the FROM clause into partitions to which the window function is applied.

Let's say we want to calculate the cumulative sum of the subscription prices for each user over time. This could help us see how much each user has spent in total at any given point in time. Let's calculate the cumulative sum of the subscription prices for each user:

SELECT user_id,
       start_date,
       price,
       SUM(price) OVER (PARTITION BY user_id ORDER BY start_date) as cumulative_price
FROM subscriptions;

Output:

Here, the cumulative_price column represents the cumulative sum of the subscription prices for each user over time.

The SUM(price) OVER (PARTITION BY user_id ORDER BY start_date) part of the query calculates this cumulative sum by summing the price for each partition of user_id, ordered by start_date. This shows how the PARTITION BY clause can be used to perform calculations within subsets of your data.

Common Table Expressions (CTEs)

A common table expression (CTE) provides the significant advantage of being able to reference itself, thereby creating a recursive CTE.

WITH monthly_revenue AS (
        SELECT DATE_TRUNC('month', start_date) as month,
               SUM(price) as revenue
        FROM subscriptions
        GROUP BY month
    )
    SELECT *
    FROM monthly_revenue
    ORDER BY month;

Output (assuming we only had data for January and February 2023):

Correlated Subqueries

A correlated subquery is a subquery that uses values from the outer query. In other words, it depends on the outer query.

SELECT u.user_id,
           (SELECT COUNT(*)
            FROM subscriptions s
            WHERE s.user_id = u.user_id) as subscription_count
    FROM users u;

Output:

PIVOT

Pivoting is a common technique in data processing, it transforms unique values from one column into multiple columns in the output, and performs aggregations where they are required on any remaining column values.

Not all databases support PIVOT. PostgreSQL, which we're using here, doesn't have a built-in PIVOT function, but we can create a pivot table using a combination of SQL commands.

SELECT
        user_id,
        COALESCE(SUM(price FILTER (WHERE DATE_TRUNC('month', start_date) = '2023-01-01')), 0) as jan_revenue,
        COALESCE(SUM(price FILTER (WHERE DATE_TRUNC('month', start_date) = '2023-02-01')), 0) as feb_revenue
    FROM subscriptions
    GROUP BY user_id;

Output:

These examples demonstrate some of the more complex techniques you can use with SQL. They can be combined and modified in a multitude of ways to perform intricate data analysis tasks.

With all that in place, let’s start using some of these techniques together in a way that a data analyst tasked with understanding revenue, growth, and churn might use them.

Revenue Analysis

Firstly, let's tackle the revenue analysis. For example, we want to find out the total revenue in January 2023.

SELECT SUM(price) as total_revenue
FROM subscriptions
WHERE start_date >= '2023-01-01' AND start_date < '2023-02-01';

This SQL statement is doing a sum aggregation on the price column of the subscriptions that started in January 2023.

Growth Analysis

Let's do some growth analysis. We want to know the growth of new users per month.

SELECT DATE_TRUNC('month', sign_up_date) as month, COUNT(*) as new_users
FROM users
GROUP BY month
ORDER BY month;

This statement uses the `DATE_TRUNC` function to group the users by the month they signed up in, then counts how many users there are in each group.

Churn Analysis

Churn analysis is slightly more complicated. For this example, let's define churn as a user not renewing their subscription at the end of a period.

WITH user_months AS (
    SELECT
        user_id,
        DATE_TRUNC('month', start_date) as start_month,
        DATE_TRUNC('month', end_date) as end_month
    FROM subscriptions
),

churned_users AS (
    SELECT
        user_id,
        COALESCE(LAG(end_month) OVER (PARTITION BY user_id ORDER BY end_month), start_month) + INTERVAL '1 month' as churn_month
    FROM user_months
    WHERE end_month IS NOT NULL
)

SELECT
    churn_month,
    COUNT(DISTINCT user_id) as churned_users
FROM churned_users
GROUP BY churn_month
ORDER BY churn_month;

This script uses a couple of advanced SQL concepts:

• Firstly, we create a Common Table Expression (CTE) called user_months to select each user's start_month and end_month from the subscriptions table.

• Then we create a second CTE churned_users where we use the LAG function to look at the previous end_month for each user. If there is no previousend_month, it means this is the user's first subscription, so we use the start_month instead. This CTE gives us the month each user churned.

• Finally, we select the churn_month and count the number of distinct users who churned in each month.

From this, we might see:

This is just the start. Given the way you can chain SQL commands together and the amount of ways to aggregate or group data, there are a ton of possibilities for data analysis in SQL.

Stored Procedures

Obviously you aren’t writing your Python code from scratch each time. You save it.

The same goes for SQL. Stored procedures are prepared SQL code that you can save and reuse over and over again.

If there is a complex query or a piece of script that you find yourself using often, you can save it as a stored procedure, and then call it to execute it whenever you need it. This can be particularly useful for complex business processes that are run regularly, such as monthly reporting, data cleansing, or data insertion processes.

Some advantages of using stored procedures are:

1. Performance: Stored procedures are parsed and optimized as soon as they are created. When you call a stored procedure for the second time, it runs faster because the database server has a cached plan for executing the query.

2. Security: Stored procedures provide an extra layer of security, as you can grant permissions to users to execute the stored procedure, instead of giving permissions on the underlying tables.

3. Reduced network traffic: If you have a complex query that involves multiple round-trips to the server, encapsulating it in a stored procedure would result in only one trip, reducing network traffic.

4. Maintenance: You can write a stored procedure once, and call it in any program where you need to perform that function. If there are changes required, you would only need to update the stored procedure and not all the individual SQL statements.

Stored procedures help to encapsulate and optimize logic that is regularly applied to your data. For our SaaS company dataset, we might have stored procedures to calculate the running total of subscription prices per user:

CREATE OR REPLACE PROCEDURE calculate_running_total(IN in_user_id INT)
    LANGUAGE plpgsql
    AS $$
    BEGIN
        RETURN QUERY
        SELECT user_id,
               start_date,
               price,
               SUM(price) OVER (PARTITION BY user_id ORDER BY start_date) as running_total
        FROM subscriptions
        WHERE user_id = in_user_id;
    END; $$

The stored procedure is mostly just SQL, with some commands around it. Let’s go through those:

• CREATE OR REPLACE PROCEDURE calculate_running_total(IN in_user_id INT): This line is creating a new stored procedure named calculate_running_total. The OR REPLACE part means that if a procedure with the same name already exists, it should be replaced with this new procedure. IN in_user_id INT is defining an input parameter named in_user_id of type INT for the procedure.

• LANGUAGE plpgsql: This specifies that the procedure will be written in the PL/pgSQL language, which is a procedural language for the PostgreSQL database system. The exact syntax to create and call stored procedures can vary between different SQL database systems.

• AS $$: This starts the definition of the procedure. In PostgreSQL, you can use $$ to denote the start and end of a function body.

• BEGIN: This keyword marks the beginning of the body of the procedure.

• RETURN QUERY: This tells PostgreSQL that the procedure will return the result of a query.

• END;: This keyword marks the end of the body of the procedure.

• $$: This marks the end of the definition of the procedure.

To call this stored procedure for a specific user (for example, user with ID 1), you would use the `CALL` statement:

CALL calculate_running_total(1);

Which would return:

Here’s an example of a stored procedure to get the monthly revenue:

CREATE OR REPLACE PROCEDURE get_monthly_revenue()
    LANGUAGE plpgsql
    AS $$
    BEGIN
        RETURN QUERY
        WITH monthly_revenue AS (
            SELECT DATE_TRUNC('month', start_date) as month,
                   SUM(price) as revenue
            FROM subscriptions
            GROUP BY month
        )
        SELECT *
        FROM monthly_revenue
        ORDER BY month;
    END; $$

To call this stored procedure, you would use the `CALL` statement:

CALL get_monthly_revenue();

Query Optimization

Query optimization is a critical aspect of database management and usage. An unoptimized query can consume excessive resources and return results slowly, impacting both server performance and user experience.

Let’s take a look at some of the queries we’ve written so far and how we might optimize them.

Reducing the number of columns in the SELECT clause

If you're only interested in the number of subscriptions per user, there's no need to select all columns from the subscriptions table:

SELECT u.user_id,
           (SELECT COUNT(*)
            FROM subscriptions s
            WHERE s.user_id = u.user_id) as subscription_count
    FROM users u;

In this case, the subquery only counts the rows in the `subscriptions` table where user_id matches the user_id from the outer query, so there's no need to fetch the full row data.

Using a WHERE clause to limit the number of rows returned

In our earlier example for the running total per user, if you're only interested in the running total for a specific user, you can add a WHERE clause to limit the number of rows returned:

SELECT user_id,
           start_date,
           price,
           SUM(price) OVER (PARTITION BY user_id ORDER BY start_date) as running_total
    FROM subscriptions
    WHERE user_id = 1;

Using appropriate indexes to speed up window function queries

In our previous example:

SELECT user_id,
           start_date,
           price,
           SUM(price) OVER (PARTITION BY user_id ORDER BY start_date) as running_total
    FROM subscriptions;

An index on user_id and start_date would likely improve performance. (Though too many indexes can slow down INSERT, UPDATE, DELETE operations, so horses for courses).

CTEs

We’ve used CTEs above and they are primarily a way to make your SQL cleaner and more readable. But, in some cases, they can be used to force the database to evaluate subqueries in a specific order, which can be used to your advantage if you understand the data and database system well.

Correlated Subqueries

Correlated subqueries can often be slow because they require the database to execute the subquery individually for each row in the outer query. If possible, it's often faster to rewrite a correlated subquery as a JOIN:

SELECT u.user_id, COUNT(s.user_id) as subscription_count
    FROM users u
    LEFT JOIN subscriptions s ON u.user_id = s.user_id
    GROUP BY u.user_id;

This query returns the same result as the correlated subquery example but may perform better, especially on large datasets, because it eliminates the need for a separate subquery for each user.

Here's some overall tips to optimize your SQL queries:

1. Use Indexes: Indexes significantly speed up data retrieval. They work similarly to an index in a book (that's why it's called an "index"). However, they can also slow down data-insertion and updating, so they are a trade-off.

2. Avoid SELECT *: When possible, avoid using `SELECT *` in your queries. Specify the exact fields you need to reduce the amount of data that needs to be retrieved and sent.

3. Use WHERE Instead of HAVING: When filtering data, use a `WHERE` clause instead of `HAVING` when possible. `WHERE` filters before data is grouped, while `HAVING` filters after, making `WHERE` more efficient.

4. Use LIMIT: If you only need a certain number of rows, use the `LIMIT` clause to reduce the amount of data that needs to be retrieved.

5. Minimize Subqueries: Subqueries can often be replaced with a `JOIN`, which is usually more efficient.

6. Use EXPLAIN: Most SQL databases have an `EXPLAIN` statement that can provide insight into how the SQL server plans to execute the query. This can help you identify parts of your query that are inefficient.

7. Avoid Complex Calculations in WHERE Clause: Calculations in a `WHERE` clause can prevent the use of indexes and slow down the query. If possible, precalculate values and store them in the database.

8. Normalize Your Database: Normalization reduces data redundancy and improves data integrity, however, in some complex query cases, denormalization might help to reduce join operations and improve query performance.

9. Use UNION ALL Instead of UNION: If you don't care about removing duplicate rows, `UNION ALL` is faster than `UNION`.

Query optimization is a subset of what might be called performance tuning. Performance tuning in SQL is all about making your queries run as fast and efficiently as possible. When working with large databases or complex queries, performance tuning can save a significant amount of time and resources, making data analysis faster and more efficient. Apart from query optimization, here are some other areas to consider when tuning SQL for data analysis:

• Database Design Optimization: Proper database design can also enhance performance. This includes things like normalization (which reduces data redundancy), appropriate use of data types, and partitioning large tables.

• Server Tuning: This involves adjusting the settings of the database and SQL server to maximize performance. This could include things like increasing buffer sizes, optimizing thread usage, or adjusting cache settings.

• Hardware Optimization: Finally, performance can be improved by upgrading the server hardware. This could include adding more memory (RAM), using faster storage devices (like SSDs), or adding more CPU cores.

SQL performance tuning is crucial, especially when dealing with large data sets. A well-tuned SQL query can retrieve and process data much faster, making the analysis process more efficient and timely. It's important to remember that performance tuning is a continuous process. As data grows and changes, what was once an optimized system may need further adjustments.

Better performance from your data analysis using SQL

You shouldn’t see SQL as just a way to read and write data from your database. SQL is an incredibly powerful language that can really increase the performance of your data analysis. Because you are performing the analysis directly in the database, you get efficient calls and less overhead. SQL data analysis can also help you prep your data for more complex analysis offline with powerful language like Python and R.

So it’s worth learning those few core commands and getting to understand aggregation and calculation directly on the data. Data analysis in SQL will help you understand your data better and give you a head start on your analysis.
